Modified Organism
SYN-IR6Ø4-5 - Agrisure™ RW Rootworm-Protected maize
Record information and status
Record ID
Date of creation
2006-06-19 10:39 UTC (kirsty.mclean.consultant@cbd.int)
Date of last update
2013-04-19 19:21 UTC (dina.abdelhakim@cbd.int)
Date of publication
2013-04-19 19:21 UTC (dina.abdelhakim@cbd.int)

Living Modified Organism identity
The image below identifies the LMO through its unique identifier, trade name and a link to this page of the BCH. Click on it to download a larger image on your computer. For help on how to use it go to the LMO quick-links page.

LMO name
Agrisure™ RW Rootworm-Protected maize
Transformation event
Unique identifier
MIR604 is a genetically modified maize developed to confer field protection against corn root worms.

The cry3A gene from Bacillus thuringiensis codes for a  Bt-toxin (Cry3A), which confers resistance to western corn rootworm (Diabrotica virgifera virgifera), northern corn rootworm (Diabrotica longicornis barberi) and other related coleopteran species.

Expression of the pmi gene from the bacterium Escherichia coli allows the plant to use mannose as a carbon source through production of the PMI protein, and is used as a selectable marker.
Recipient Organism or Parental Organisms
The term Recipient organism refers to an organism (either already modified or non-modified) that was subjected to genetic modification, whereas Parental organisms refers to those that were involved in cross breeding or cell fusion.
Zea mays - Maize, Corn, MAIZE
Characteristics of the transformation process
Techniques used for the modification
  • Agrobacterium-mediated DNA transfer
Genetic elements construct
Metallothionein-like gene promoter
2.56 Kb
1.80 Kb
Nopaline Synthase Gene Terminator
0.25 Kb
Ubiquitin gene promoter
0.98 Kb
Ubiquitin Intron 1
1.01 Kb
Phosphomannose Isomerase gene
1.18 Kb
Nopaline Synthase Gene Terminator
0.25 Kb
Further details
Notes regarding the genetic elements introduced or modified in this LMO
Cry3A gene obtained from Bacillus thuringiensis. The gene was modified for enhanced expression in maize and such that the amino acid sequence of the synthetic version of Cry3A is the same as the native protein, except for the modified serine-protease recognition site.

The pmi gene encodes the enzyme phosphomannose isomerase (PMI) that allows the plants to utilise mannose as a carbon source and is used as a selectable marker.

Truncations at the left and right border junctions of the T-DNA insert as well as nucleotide changes were identified relative to the intended DNA sequence. These substitutions have not resulted in any apparent functional change in PMI as expressed in MIR604.

Southern hybridization data provide confirmatory evidence to support the Taqman PCR analysis that Corn MIR604 contains a single copy of mcry3A gene and the pmi gene.

Corn MIR604 contains a single copy of the MTL and ZmUbilnt promoters, without any vector backbone sequences present in pZM26. Sequence analysis revealed that truncations and deletions occurred but have no effect on the efficacy of the T-DNA insert. Three base pair changes were noted; one occurred in the regulatory region and does not encode for a protein; two other base pair changes occurred within the coding region but these amino acid changes did not result in any apparent functional change in the new insert.

As expected for the mcry3A, pmi, MTL and ZmUbilnt probes the Kpn1 digest resulted in a single hybridization band demonstrating that a single copy of each element is present in Corn MIR604.  Additionally, for the full length backbone probe, lack of hybridization demonstrates the absence of any pZM26 vector backbone sequences being incorporated into corn MIR604 during the transformation process.
LMO characteristics
Modified traits
Additional Information
Other relevant website address or attached documents
