Living Modified Organism
(LMO)
The image below identifies the LMO through its unique identifier, trade name and a link to this page of the BCH. Click on it to download a larger image on your computer. For help on how to use it go to the LMO quick-links page.
Maize modified for herbicide tolerance and insect resistance
EN
4114 × MON810 × MIR604 × NK603
Yes
DP-ØØ4114-3 × MON-ØØ81Ø-6 × SYN-IR6Ø4-5 × MON-ØØ6Ø3-6
-
Organization:Monsanto ()800 North Lindbergh Blvd.St. Louis, MO
63167, United States of AmericaPhone: + 1 314 694-1000,Fax: +1 314 694-3080,Email:Website: http://www.monsanto.com, -
Organization:Syngenta Seeds GmbH ()Private sector (business and industry)Syngenta Seeds GmbH Zum Knipkenbach 20Bad Salzuflen,
32107, GermanyPhone: +49 52 22 5308-0,Fax: +49 52 22 5308-12,Email: info.seeds@syngenta.com,Website: http://www.syngenta-seeds.de/de/,
NK603 x MON810 x 4114 x MIR 604 maize is the product of the conventional breeding of each of the parental organisms to produce maize that expresses each of cry34Ab1, cry35Ab1, cryIF, PAT, Cry1Ab, mCry3A, PMI and EPSPS. The expression of these genes are expected to confer resistance to Lepidoptera and Coleoptera, and tolerance to glufosinate herbicide and glyphosate herbicide.
EN
The term “Recipient organism” refers to an organism (either already modified or non-modified) that was subjected to genetic modification, whereas “Parental organisms” refers to those that were involved in cross breeding or cell fusion.
-
BCH-ORGA-SCBD-246-6 Organism Zea mays (Maize, Corn, MAIZE)Crops
-
BCH-LMO-SCBD-104976-2 Living Modified Organism DP-ØØ4114-3 - Insect-Resistant and Herbicide-Tolerant MaizePioneer Hi-Bred International Inc. | Resistance to diseases and pests (Insects, Coleoptera (beetles), Lepidoptera (butterflies and moths)), Resistance to herbicides (Glufosinate)
-
BCH-LMO-SCBD-14750-19 Living Modified Organism MON-ØØ81Ø-6 - YieldGard™ maizeMonsanto | Resistance to diseases and pests (Insects, Lepidoptera (butterflies and moths), European corn borer (Ostrinia nubilalis))
-
BCH-LMO-SCBD-15105-12 Living Modified Organism SYN-IR6Ø4-5 - Agrisure™ RW Rootworm-Protected maizeResistance to diseases and pests (Insects, Coleoptera (beetles))
-
BCH-LMO-SCBD-14776-17 Living Modified Organism MON-ØØ6Ø3-6 - Roundup Ready™ maizeMonsanto | Resistance to herbicides (Glyphosate)
EN
PHP27118, PV-ZMBK07, PV-ZMGT10, pZM26 and PV-ZMGT32
EN
- Cross breeding
0.980 kb
|
1.010 kb
|
1.180 kb
|
0.250 kb
|
2.560 kb
|
1.800 kb
|
0.250 kb
|
0.600 kb
|
0.800 kb
|
0.200 kb
|
1.400 kb
|
0.300 kb
|
0.800 kb
|
0.600 kb
|
0.200 kb
|
1.400 kb
|
0.300 kb
|
0.980 kb
|
1.010 kb
|
1.820 kb
|
0.710 kb
|
0.980 kb
|
1.010 kb
|
0.370 kb
|
0.310 kb
|
1.290 kb
|
1.150 kb
|
0.310 kb
|
0.530 kb
|
0.550 kb
|
0.190 kb
|
Some of these genetic elements may be present as fragments or truncated forms. Please see notes below, where applicable.
-
BCH-GENE-SCBD-100362-7 Ubiquitin gene promoter | Zea mays (Maize, Corn, MAIZE)Promoter
-
BCH-GENE-SCBD-103627-5 Ubiquitin Intron 1 | Zea mays (Maize, Corn, MAIZE)Intron
-
BCH-GENE-SCBD-14987-8 Cry1F | Bacillus thuringiensis (Bt, Bacillus, BACTU)Protein coding sequence | Resistance to diseases and pests (Insects, Lepidoptera (butterflies and moths))
-
BCH-GENE-SCBD-100363-5 ORF25 PolyA Terminator sequence | Agrobacterium tumefaciens (Agrobacterium)Terminator
-
BCH-GENE-SCBD-14994-9 Cry34Ab1 | Bacillus thuringiensis (Bt, Bacillus, BACTU)Protein coding sequence | Resistance to diseases and pests (Insects, Coleoptera (beetles))
-
BCH-GENE-SCBD-100367-4 Proteinase inhibitor II gene terminator | Solanum tuberosum (Potato, SOLTU)Terminator
-
BCH-GENE-SCBD-100368-6 Peroxidase gene promoter | Triticum aestivum (Wheat)Promoter
-
BCH-GENE-SCBD-14995-8 Cry35Ab1 | Bacillus thuringiensis (Bt, Bacillus, BACTU)Protein coding sequence | Resistance to diseases and pests (Insects, Coleoptera (beetles))
-
BCH-GENE-SCBD-100287-7 CaMV 35S promoter | Cauliflower mosaic virus (CaMV)Promoter
-
BCH-GENE-SCBD-15002-4 Phosphinothricin N-acetyltransferase gene | Streptomyces viridochromogenes (STRVR)Protein coding sequence | Resistance to herbicides (Glufosinate)
-
BCH-GENE-SCBD-100290-6 CaMV 35S terminator | Cauliflower mosaic virus (CaMV)Terminator
-
BCH-GENE-SCBD-15003-7 Phosphomannose Isomerase gene | Escherichia coli (ECOLX)Protein coding sequence | Mannose tolerance,Selectable marker genes and reporter genes
-
BCH-GENE-SCBD-100269-8 Nopaline Synthase Gene Terminator | Agrobacterium tumefaciens (Agrobacterium)Terminator
-
BCH-GENE-SCBD-103881-2 Metallothionein-like gene promoter | Zea mays (Maize, Corn, MAIZE)Promoter
-
BCH-GENE-SCBD-43634-3 mCry3A | Bacillus thuringiensis (Bt, Bacillus, BACTU)Protein coding sequence | Resistance to diseases and pests (Insects, Coleoptera (beetles), Western corn rootworm (Diabrotica virgifera))
-
BCH-GENE-SCBD-100366-6 CaMV Enhanced 35S promoter | Cauliflower mosaic virus (CaMV)Promoter
-
BCH-GENE-SCBD-100359-7 Hsp70 intron | Zea mays (Maize, Corn, MAIZE)Intron
-
BCH-GENE-SCBD-14985-12 Cry1Ab | Bacillus thuringiensis (Bt, Bacillus, BACTU)Protein coding sequence | Resistance to diseases and pests (Insects, Lepidoptera (butterflies and moths))
-
BCH-GENE-SCBD-100365-6 Chloroplast transit peptide 2 | Arabidopsis thaliana (Thale cress, Mouse-ear cress, Arabidopsis, ARATH)Transit signal
-
BCH-GENE-SCBD-14979-7 5-enolpyruvylshikimate-3-phosphate synthase gene | Agrobacterium tumefaciens (Agrobacterium)Protein coding sequence | Resistance to herbicides (Glyphosate)
-
BCH-GENE-SCBD-100364-5 Rice actin 1 gene promoter | Oryza sativa (Rice, ORYSA)Promoter
-
BCH-GENE-SCBD-100355-6 Rice actin 1, intron | Oryza sativa (Rice, ORYSA)Intron
DNA insert from NK603, vector PV-ZMGT32:
NK603 contains a form of the plant enzyme 5-enolpyruvylshikimate-3-phosphate synthase (EPSPS) that allows the plant to survive the otherwise lethal application of glyphosate.
DNA insert from MON810, vectors PV-ZMBK07 and PV-ZMGT10:
MON810 contains a truncated portion of a synthetic form of the cry1Ab gene. Two constructs PV-ZMBK07 and PV-ZMGT10 have been used for transformation, but molecular analyses showed that MON810 does not contain any element from PV-ZMGT10 construct and only the elements from construct PV-ZMBK07 have been integrated into its genome. MON810 contains one integrated DNA consisting of P-e35S, I-Hsp70 and cry1Ab. The terminator of the nopaline synthase (nos) gene was lost due to a truncation at the 3' end of the gene cassette during genome integration and is, therefore, not present in MON810.
DNA insert from MIR604 vector pZM26
Cry3A gene was modified for enhanced expression in maize and such that the amino acid sequence of the synthetic version of Cry3A is the same as the native protein, except for the modified serine-protease recognition site. The pmi gene encodes the enzyme phosphomannose isomerase (PMI) that allows the plants to utilise mannose as a carbon source and is used as a selectable marker.
DNA insert from 4114, vector PHP27118:
An insect-resistant and herbicide-tolerant maize. Insect resistance is conferred by the cry34Ab1, cry35Ab1 and cryIF genes from the common soil bacterium Bacillus thuringiensis, and glufosinate-ammonium herbicide tolerance through the pat gene from Streptomyces viridochromogenes.
For additional information on this LMO, please refer to the records of the parental LMOs.
EN
NK603 contains a form of the plant enzyme 5-enolpyruvylshikimate-3-phosphate synthase (EPSPS) that allows the plant to survive the otherwise lethal application of glyphosate.
DNA insert from MON810, vectors PV-ZMBK07 and PV-ZMGT10:
MON810 contains a truncated portion of a synthetic form of the cry1Ab gene. Two constructs PV-ZMBK07 and PV-ZMGT10 have been used for transformation, but molecular analyses showed that MON810 does not contain any element from PV-ZMGT10 construct and only the elements from construct PV-ZMBK07 have been integrated into its genome. MON810 contains one integrated DNA consisting of P-e35S, I-Hsp70 and cry1Ab. The terminator of the nopaline synthase (nos) gene was lost due to a truncation at the 3' end of the gene cassette during genome integration and is, therefore, not present in MON810.
DNA insert from MIR604 vector pZM26
Cry3A gene was modified for enhanced expression in maize and such that the amino acid sequence of the synthetic version of Cry3A is the same as the native protein, except for the modified serine-protease recognition site. The pmi gene encodes the enzyme phosphomannose isomerase (PMI) that allows the plants to utilise mannose as a carbon source and is used as a selectable marker.
DNA insert from 4114, vector PHP27118:
An insect-resistant and herbicide-tolerant maize. Insect resistance is conferred by the cry34Ab1, cry35Ab1 and cryIF genes from the common soil bacterium Bacillus thuringiensis, and glufosinate-ammonium herbicide tolerance through the pat gene from Streptomyces viridochromogenes.
For additional information on this LMO, please refer to the records of the parental LMOs.
EN
- Feed
- Food
- DP-ØØ4114-3 - EU Reference Laboratory for GM Food and Feed (EURL-GMFF) ( JRC ) [ English ]
- MON-ØØ6Ø3-6 - EU Reference Laboratory for GM Food and Feed (EURL-GMFF) ( JRC ) [ English ]
- MON-ØØ81Ø-6 - EU Reference Laboratory for GM Food and Feed (EURL-GMFF) ( JRC ) [ English ]
- SYN-IR6Ø4-5 - EU Reference Laboratory for GM Food and Feed (EURL-GMFF) ( JRC ) [ English ]
- MON-ØØ81Ø-6 - CropLife International Detection Methods Database ( CropLife ) [ English ]
- SYN-IR6Ø4-5 - CropLife International Detection Methods Database ( CropLife ) [ English ]
- MON-ØØ6Ø3-6 - CropLife International Detection Methods Database ( CropLife ) [ English ]
