Living Modified Organism (LMO)
  |
|
Decisions on the LMO Risk Assessments
last updated: 01 Sep 2014
Living Modified Organism identity
The image below identifies the LMO through its unique identifier, trade name and a link to this page of the BCH. Click on it to download a larger image on your computer. For help on how to use it go to the LMO quick-links page.
Insect resistant, herbicide tolerant maize
EN
MON89034 x TC1507 x MON88017 x DAS59122 x DAS40278
Yes
MON-89Ø34-3 × DAS-Ø15Ø7-1 × MON-88Ø17-3 × DAS-59122-7 × DAS-4Ø278-9
  • - Organization: Dow AgroScience () | BCH-CON-MX-8035-1
    Organization:
    Dow AgroScience ()
    Phone:
    Fax:
    Email:
    Website:
The stacked maize line MON-89Ø34-3 x DAS-Ø15Ø7-1 x MON-88Ø17-3 x DAS-59122-7 x DAS-4Ø278-9 was obtained through the traditional cross breading of each of the parental organisms to produce a maize that expresses each of aryloxyalkanoate dioxygenase, Cry1A.105, Cry2Ab2, Cry1F, PAT, EPSPS, Cry3Bb1, Cry34Ab1 and Cry35Ab1 genes. The expression of these genes are expected to confer resistance to Lepidoptera and Coleoptera, and tolerant to 2,4-dichlorophenoxyacetic acid (2,4-D) and aryloxyphenoxypropionate (AOPP) acetyl coenzyme A carboxylase (ACCase) inhibitors, glufosinate herbicide and glyphosate herbicide.
EN
The term “Recipient organism” refers to an organism (either already modified or non-modified) that was subjected to genetic modification, whereas “Parental organisms” refers to those that were involved in cross breeding or cell fusion.
  • BCH-ORGA-SCBD-246-6 Organism Zea mays (Maize, Corn, MAIZE)
    Crops
  • BCH-LMO-SCBD-104814-2 Living Modified Organism DAS-4Ø278-9 - Enlist™ Maize
    Dow AgroSciences GmbH | Resistance to herbicides, Tolerance to 2,4-Dichlorophenoxyacetic acid, Tolerance to aryloxyphenoxypropionate
  • BCH-LMO-SCBD-15165-13 Living Modified Organism DAS-59122-7 - Herculex™ RW Rootworm Protection maize
    Pioneer Hi-Bred International Inc. | Resistance to diseases and pests (Insects, Coleoptera (beetles)), Resistance to herbicides (Glufosinate)
  • BCH-LMO-SCBD-15106-10 Living Modified Organism MON-88Ø17-3 - YieldGard™ VT™ Rootworm/RR2™ Maize
    Monsanto | Resistance to diseases and pests (Insects, Coleoptera (beetles)), Resistance to herbicides (Glyphosate)
  • BCH-LMO-SCBD-14841-16 Living Modified Organism DAS-Ø15Ø7-1 - Herculex™ I maize
    Dow AgroSciences, Pioneer Hi-Bred International Inc. | Resistance to diseases and pests (Insects, Lepidoptera (butterflies and moths), European corn borer (Ostrinia nubilalis)), Resistance to herbicides (Glufosinate)
  • BCH-LMO-SCBD-43773-18 Living Modified Organism MON-89Ø34-3 - YieldGard™ VT Pro™
    Resistance to diseases and pests (Insects, Lepidoptera (butterflies and moths))
EN
Characteristics of the modification process
pDAS1740, PHP17662, PV-ZMIR39, PHI8999A and PV-ZMIR245
EN
  • Cross breeding

1.980 kb


1.820 kb


0.720 kb

Some of these genetic elements may be present as fragments or truncated forms. Please see notes below, where applicable.
  • BCH-GENE-SCBD-43771-9 Cry1A.105 | Bacillus thuringiensis (Bt, Bacillus, BACTU)
    Protein coding sequence | Resistance to diseases and pests (Insects, Lepidoptera (butterflies and moths))
  • BCH-GENE-SCBD-14988-7 Cry2Ab2 | Bacillus thuringiensis (Bt, Bacillus, BACTU)
    Protein coding sequence | Resistance to diseases and pests (Insects, Lepidoptera (butterflies and moths))
  • BCH-GENE-SCBD-14987-8 Cry1F | Bacillus thuringiensis (Bt, Bacillus, BACTU)
    Protein coding sequence | Resistance to diseases and pests (Insects, Lepidoptera (butterflies and moths))
  • BCH-GENE-SCBD-14993-5 Cry3Bb1 | Bacillus thuringiensis (Bt, Bacillus, BACTU)
    Protein coding sequence | Resistance to diseases and pests (Insects, Coleoptera (beetles))
  • BCH-GENE-SCBD-15002-5 Phosphinothricin N-acetyltransferase | Streptomyces viridochromogenes (STRVR)
    Protein coding sequence | Resistance to herbicides (Glufosinate)
  • BCH-GENE-SCBD-14979-7 5-enolpyruvylshikimate-3-phosphate synthase gene | Agrobacterium tumefaciens (Agrobacterium)
    Protein coding sequence | Resistance to herbicides (Glyphosate)
  • BCH-GENE-SCBD-104812-3 Aryloxyalkanoate dioxygenase gene | Sphingobium herbicidovorans (SPHHE)
    Protein coding sequence | Resistance to herbicides,Tolerance to 2,4-Dichlorophenoxyacetic acid,Tolerance to aryloxyphenoxypropionate
  • BCH-GENE-SCBD-104795-4 RB7 matrix attachment region | Nicotiana tabacum (Tobacco, TOBAC )
    Enhancer
  • BCH-GENE-SCBD-100362-7 Ubiquitin gene promoter | Zea mays (Maize, Corn, MAIZE)
    Promoter
  • BCH-GENE-SCBD-104813-4 Per5 3' Untranslated Region | Zea mays (Maize, Corn, MAIZE)
    Terminator
  • BCH-GENE-SCBD-14994-9 Cry34Ab1 | Bacillus thuringiensis (Bt, Bacillus, BACTU)
    Protein coding sequence | Resistance to diseases and pests (Insects, Coleoptera (beetles))
  • BCH-GENE-SCBD-100367-4 Proteinase inhibitor II gene terminator | Solanum tuberosum (Potato, SOLTU)
    Terminator
  • BCH-GENE-SCBD-100368-6 Peroxidase gene promoter | Triticum aestivum (Wheat)
    Promoter
  • BCH-GENE-SCBD-14995-8 Cry35Ab1 | Bacillus thuringiensis (Bt, Bacillus, BACTU)
    Protein coding sequence | Resistance to diseases and pests (Insects, Coleoptera (beetles))
  • BCH-GENE-SCBD-100366-6 CaMV Enhanced 35S promoter | Cauliflower mosaic virus (CaMV)
    Promoter
  • BCH-GENE-SCBD-100354-6 5' untranslated leader from chlorophyll a/b-binding protein | Triticum aestivum (Wheat)
    Leader sequence
  • BCH-GENE-SCBD-100355-6 Rice actin 1, intron | Oryza sativa (Rice, ORYSA)
    Intron
  • BCH-GENE-SCBD-100356-6 Heat shock protein 17.3 terminator | Triticum aestivum (Wheat)
    Terminator
  • BCH-GENE-SCBD-101507-5 FMV 34S promoter | Figwort mosaic virus (Figwort mottle virus, FMV, CMoVb)
    Promoter
  • BCH-GENE-SCBD-100359-7 Hsp70 intron | Zea mays (Maize, Corn, MAIZE)
    Intron
  • BCH-GENE-SCBD-100360-4 Transit peptide and first intron of Rubisco SSU | Zea mays (Maize, Corn, MAIZE)
    Transit signal
  • BCH-GENE-SCBD-100269-8 Nopaline Synthase Gene Terminator | Agrobacterium tumefaciens (Agrobacterium)
    Terminator
  • BCH-GENE-SCBD-100363-5 ORF25 PolyA Terminator sequence | Agrobacterium tumefaciens (Agrobacterium)
    Terminator
  • BCH-GENE-SCBD-100287-7 CaMV 35S promoter | Cauliflower mosaic virus (CaMV)
    Promoter
  • BCH-GENE-SCBD-100290-6 CaMV 35S terminator | Cauliflower mosaic virus (CaMV)
    Terminator
  • BCH-GENE-SCBD-100364-5 Rice actin 1 gene promoter | Oryza sativa (Rice, ORYSA)
    Promoter
  • BCH-GENE-SCBD-100365-6 Chloroplast transit peptide 2 | Arabidopsis thaliana (Thale cress, Mouse-ear cress, Arabidopsis, ARATH)
    Transit signal
DNA insert from MON89034 vector PV-ZMIR245
MON89034 contributed the Cry1A.105 and Cry2A(b) coding sequences and their associated regulatory elements. These confer resistance against lepidopteran pests.

DNA insert from TC1507 vector PHI8999A
The TC1507 line contained the Cry1F and PAT coding sequences and regulatory elements. The Cry1F gene produces insecticidal crystal protein that confers resistance against lepidopteran pests and the PAT gene produces Phosphinothricin N-acetyltransferase which confers tolerance to the glufosinate herbicide.

DNA insert from DAS40278 vector pDAS1740
DAS-40278-9 corn was modified with the insertion of a plant optimised coding sequence for aryloxyalkanoate dioxygenase to confer tolerance to the herbicides 2,4-dichlorophenoxyacetic acid (2,4-D) and aryloxyphenoxypropionate (AOPP) acetyl coenzyme A carboxylase (ACCase) inhibitors.

DNA insert from 59122 vector PHP17662
The cry34Ab1 and cry35Ab1 genes, isolated from the common soil bacterium Bacillus thuringiensis (Bt) strain PS149B1, produce the insect control proteins (delta-endotoxins) Cry34Ab1 and Cry35Ab1. The pat gene was isolated from the soil bacterium Streptomyces viridochromogenes and confers tolerance to herbicides containing glufosinate ammonium.

DNA insert from MON88017 vector PV-ZMIR39
MON88017 expresses the cry3Bb1 gene encoding a Coleopteran-specific insecticidal protein to control infestation with corn root worm, and the cp4 epsps gene.

For additional information on this LMO, please refer to the records of the parental LMOs.
EN
LMO characteristics
EN
  • Food
  • Feed
Detection method(s)
EN
Additional Information
EN
Records referencing this document Show in search
Record type Field Record(s)
Laboratory for detection and identification of LMOs LMO(s) detectable by the laboratory 1
Country's Decision or any other Communication LMO identification 4
Risk Assessment generated by a regulatory process Living modified organism(s) 5
