Living Modified Organism (LMO)
  |
|
Decisions on the LMO Risk Assessments
published: 30 May 2022 last updated: 31 May 2022
Living Modified Organism identity
The image below identifies the LMO through its unique identifier, trade name and a link to this page of the BCH. Click on it to download a larger image on your computer. For help on how to use it go to the LMO quick-links page.
Male-sterile Anopheles coluzzii mosquitoes
EN
Ag(DSM)2 (Ac(DSM)2)
No
The modified Anopheles coluzzii (Ac(DSM)2) was produced by crossing modified Anopheles gambiae (Ag(DSM)2) with wild-type An. coluzzii. The modified mosquitoes are male-sterile and express a fluorescent marker. For sterility, the modified mosquito expresses a homing endonuclease gene (Physarum polycephalum intron-encoded endonuclease; I-PpoI) in testes tissues, which cuts a ribosomal DNA sequence on the X chromosome during male spermatogenesis. However, all spermatozoa, irrespectively of the inheritance of the gene cassettes, carried a substantial amount of I-PpoI protein. Thus, upon mating and fertilization of the egg, the maternal X chromosome is also cut due to the activity of I-PpoI delivered from the sperm, leading to developmental arrest of embryos and no viable progeny. Thus, the destruction of the X chromosomes renders the male mosquitoes sexually sterile and unable to father viable progeny as a result of the I-PpoI activity on the X chromosome. In addition, the I-PpoI endonuclease is fused to Aequorea victoria enhanced green fluorescent protein, which was used to verify expression of I-PoI in the testes. The modified mosquito also expresses Discosoma sp. red fluorescent protein (DsRed2), which acts as a marker, being expressed in the eyes of the modified mosquitoes. The strain is maintained in the laboratory by crossing Ac(DSM)2 females, identified by red fluorescent eyes with wild-type males.
EN
The term “Recipient organism” refers to an organism (either already modified or non-modified) that was subjected to genetic modification, whereas “Parental organisms” refers to those that were involved in cross breeding or cell fusion.
  • BCH-ORGA-SCBD-260477-2 Organism Anopheles coluzzii (African malaria mosquito, Malaria mosquito, Mosquito)
    Insects
  • BCH-LMO-SCBD-260489-1 Living Modified Organism Male-sterile Anopheles gambiae mosquitoes
    Institut de Recherche en Sciences de la Santé (IRSS), Direction Régionale de l’Ouest(IRSS) | Changes in physiology and/or production (Reproduction, Male sterility), Changes in quality and/or metabolite content (Pigmentation / Coloration), Selectable marker genes and reporter genes
MRA-112 Anopheles coluzzii from IRSS, Burkina Faso
EN
Characteristics of the modification process
pBac{3xP3-DsRed}b2-eGFPI-PpoI
EN
  • Cross breeding

0.000 kb


0.000 kb


0.000 kb


0.000 kb

Some of these genetic elements may be present as fragments or truncated forms. Please see notes below, where applicable.
  • BCH-GENE-SCBD-103740-1 Red Fluorescent Protein gene | Discosoma sp. (Coral anemones, Sea anemones)
    Protein coding sequence | Selectable marker genes and reporter genes
  • BCH-GENE-SCBD-115246-2 piggyBac | Trichoplusia ni - Cabbage looper, Cabbage looper moth, Cabbage plusia, Common cabbage looper, Lettuce looper
    Transposon
  • BCH-GENE-SCBD-114748-3 SV40 poly-adenylation signal | Macaca mulatta polyomavirus 1 (SV40, Simian vacuolating virus 40, simian virus 40, Rhesus macaque polyomavirus)
    Terminator
  • BCH-GENE-SCBD-260479-1 3xP3 promoter | Drosophila melanogaster (Common Fruit Fly)
    Promoter
  • BCH-GENE-SCBD-101476-6 DsRed2 Fluorescent Protein | Discosoma sp. (Coral anemones, Sea anemones)
    Protein coding sequence | Changes in quality and/or metabolite content (Pigmentation / Coloration)
  • BCH-GENE-SCBD-260481-1 Beta-2 tubulin promoter | Anopheles gambiae (African malaria mosquito, Mosquito, Malaria mosquito, ANOGA)
    Promoter
  • BCH-GENE-SCBD-260488-1 Enhanced green fluorescent protein | Aequorea victoria (Crystal Jellyfish, Water Jellyfish, AEQVI)
    Protein coding sequence | Changes in quality and/or metabolite content (Pigmentation / Coloration),Selectable marker genes and reporter genes
  • BCH-GENE-SCBD-260487-4 Intron-encoded endonuclease | Physarum polycephalum (Plasmodial slime molds, Slime mold, PHYPO)
    Protein coding sequence | Changes in physiology and/or production (Reproduction, Male sterility),Engineered gene drive application (Population suppression)
  • BCH-GENE-SCBD-260483-1 Beta-2 tubulin terminator | Anopheles gambiae (African malaria mosquito, Mosquito, Malaria mosquito, ANOGA)
    Terminator
The modified Anopheles coluzzii mosquitoes contain two gene cassettes: Discosoma sp. red fluorescent protein DsRed2 and an Aequorea victoria enhanced green fluorescent protein-Physarum polycephalum intron-encoded endonuclease (eGFP::I-Ppol) fusion protein. The non-autonomous Trichoplusia ni piggyBac transposable element was used to insert the gene cassettes into the germline of the modified mosquitoes.

The DsRed2 coding sequence is under control of the synthetic 3xP3 promoter and the Macaca mulatta polyomavirus 1 SV40 polyadenylation signal. The photoreceptor-specific nature of the promoter restricts expression of DsRed2 to the eyes of the modified mosquito.

The eGFP::I-Ppol coding sequence is under control of an Anopheles gambiae beta-2 tubulin promoter and terminator. Due to the nature of the promoter, expression of the eGFP::I-Ppol is expected to be restricted to male spermatogenesis in the testes. The eGFP protein makes up the N-terminal region of the fusion protein, while I-PpoI is on the C-terminal end.
EN
LMO characteristics
EN
  • Research
Detection method(s)
Modified adult mosquitoes can be detected by the red fluorescence in their eye lobes due to the presence of the DsRed2 protein.
EN
Additional Information
Anopheles gambiae sensu lato (s.l.) is a species complex, whose members are morphologically indistinguishable in their adult stage but isolated reproductively. They have distinct genetic and behavioural traits. Thus, their identification relies on molecular methods. While hybrid males from most crosses between species of the An. gambiae complex are sterile, males from crosses between An. gambiae and An. coluzzii do not show signatures of genetic incompatibilities and are fully fertile, with no obvious loss in fitness under laboratory conditions.

The main malaria vectors in the complex are An. gambiae, An. coluzzii, and An. arabiensis.

Target Malaria's work in Burkina Faso is led by the Institut de Recherche en Sciences de la Santé (IRSS).
EN
