Living Modified Organism
(LMO)
The image below identifies the LMO through its unique identifier, trade name and a link to this page of the BCH. Click on it to download a larger image on your computer. For help on how to use it go to the LMO quick-links page.
Insect-resistant maize
EN
MIR162 × MON89034 × 5307
Yes
SYN-IR162-4 × MON-89Ø34-3 × SYN-Ø53Ø7-1
-
Organization:Syngenta Seeds GmbH ()Private sector (business and industry)Syngenta Seeds GmbH Zum Knipkenbach 20Bad Salzuflen,
32107, GermanyPhone: +49 52 22 5308-0,Fax: +49 52 22 5308-12,Email: info.seeds@syngenta.com,Website: http://www.syngenta-seeds.de/de/, -
Organization:Bayer CropScience ()Phone:Fax:Email:Website: http://www.bayercropscience.com,
The maize (Zea mays) was produced through crossing modified parental lines for resistance to insect pests. For protection from Lepidoptera insects, the maize expresses Bacillus thuringiensis Cry1A.105, Cry2Ab2 and VIP3Aa20 proteins, which have a pore-forming mode of action that selectively damages the midgut epithelium line of feeding larvae. For resistance to Coleoptera pests, the modified maize expresses B. thuringiensis eCry3.1Ab , which also has a pore forming mode of action. In addition, the modified maize also contains gene cassettes for Escherichia coli phosphomannose isomerase, which was used as a selectable marker during transformation by allowing for the transformed maize plants to tolerate the presence of mannose.
The term “Recipient organism” refers to an organism (either already modified or non-modified) that was subjected to genetic modification, whereas “Parental organisms” refers to those that were involved in cross breeding or cell fusion.
-
BCH-ORGA-SCBD-246-6 Organism Zea mays (Maize, Corn, MAIZE)Crops
-
BCH-LMO-SCBD-100885-13 Living Modified Organism SYN-IR162-4 - Agrisure™ Viptera maizeResistance to diseases and pests (Insects, Lepidoptera (butterflies and moths))
-
BCH-LMO-SCBD-43773-18 Living Modified Organism MON-89Ø34-3 - YieldGard™ VT Pro™Resistance to diseases and pests (Insects, Lepidoptera (butterflies and moths))
-
BCH-LMO-SCBD-104791-4 Living Modified Organism SYN-Ø53Ø7-1 - Agrisure® Duracade™ MaizeSyngenta Seeds GmbH | Resistance to diseases and pests (Insects, Coleoptera (beetles), Western corn rootworm (Diabrotica virgifera), Northern corn rootworm (Diabrotica barberi))
EN
pNOV1300; PV-ZMIR245; pSYN12274
EN
- Cross breeding
|
1.993 kb
|
|
2.370 kb
|
|
0.108 kb
|
|
0.070 kb
|
|
1.993 kb
|
|
1.176 kb
|
|
0.253 kb
|
|
0.300 kb
|
|
0.060 kb
|
|
0.480 kb
|
|
3.530 kb
|
|
0.210 kb
|
|
0.560 kb
|
|
0.800 kb
|
|
0.400 kb
|
|
1.910 kb
|
|
0.250 kb
|
|
0.346 kb
|
|
1.960 kb
|
|
0.253 kb
|
|
1.993 kb
|
|
1.176 kb
|
|
0.253 kb
|
Some of these genetic elements may be present as fragments or truncated forms. Please see notes below, where applicable.
-
BCH-GENE-SCBD-100362-7 Ubiquitin gene promoter | Zea mays (Maize, Corn, MAIZE)Promoter
-
BCH-GENE-SCBD-100887-5 Vegetative insecticidal protein 3Aa20 | Bacillus thuringiensis (Bt, Bacillus, BACTU)Protein coding sequence | Resistance to diseases and pests (Insects, Lepidoptera (butterflies and moths))
-
BCH-GENE-SCBD-101406-4 Phosphoenolpyruvate carboxylase, intron 9 | Zea mays (Maize, Corn, MAIZE)Intron
-
BCH-GENE-SCBD-100290-6 CaMV 35S terminator | Cauliflower mosaic virus (CaMV)Terminator
-
BCH-GENE-SCBD-15003-7 Phosphomannose Isomerase gene | Escherichia coli (ECOLX)Protein coding sequence | Mannose tolerance,Selectable marker genes and reporter genes
-
BCH-GENE-SCBD-100269-8 Nopaline Synthase Gene Terminator | Agrobacterium tumefaciens (Agrobacterium)Terminator
-
BCH-GENE-SCBD-100366-6 CaMV Enhanced 35S promoter | Cauliflower mosaic virus (CaMV)Promoter
-
BCH-GENE-SCBD-100354-6 5' untranslated leader from chlorophyll a/b-binding protein | Triticum aestivum (Wheat)Leader sequence
-
BCH-GENE-SCBD-100355-6 Rice actin 1, intron | Oryza sativa (Rice, ORYSA)Intron
-
BCH-GENE-SCBD-43771-9 Cry1A.105 | Bacillus thuringiensis (Bt, Bacillus, BACTU)Protein coding sequence | Resistance to diseases and pests (Insects, Lepidoptera (butterflies and moths))
-
BCH-GENE-SCBD-100356-6 Heat shock protein 17.3 terminator | Triticum aestivum (Wheat)Terminator
-
BCH-GENE-SCBD-101507-5 FMV 34S promoter | Figwort mosaic virus (Figwort mottle virus, FMV, CMoVb)Promoter
-
BCH-GENE-SCBD-100359-7 Hsp70 intron | Zea mays (Maize, Corn, MAIZE)Intron
-
BCH-GENE-SCBD-100360-4 Transit peptide and first intron of Rubisco SSU | Zea mays (Maize, Corn, MAIZE)Transit signal
-
BCH-GENE-SCBD-14988-7 Cry2Ab2 | Bacillus thuringiensis (Bt, Bacillus, BACTU)Protein coding sequence | Resistance to diseases and pests (Insects, Lepidoptera (butterflies and moths))
-
BCH-GENE-SCBD-104788-2 Cestrum Yellow Leaf Curling Virus promoter | Cestrum yellow leaf curling virus (CYLCV)Promoter
-
BCH-GENE-SCBD-104789-2 eCry3.1Ab | Bacillus thuringiensis (Bt, Bacillus, BACTU)Protein coding sequence | Resistance to diseases and pests (Insects, Coleoptera (beetles), Western corn rootworm (Diabrotica virgifera), Northern corn rootworm (Diabrotica barberi))
DNA insert from MIR162 (SYN-IR162-4) vector pNOV1300
The parental genome contains two gene cassettes: a variant of the native B. thuringiensis vegetative insecticidal protein 3Aa (vip3Aa20) and E. coli phosphomannose isomerase.
Transcription of vip3Aa20 commences at the Z. mays ubiquitin promoter and then transcribes vip3Aa20 followed by intron 9 of Z. mays phosphoenolpyruvate carboxylase, before terminating at the CaMV 35S terminator. Nigher levels of expression are expected due to the promoter and the enhancement by the intron.
The pmi coding sequence is under the control of Z. mays ubiquitin promoter and transcription terminates at the Agrobacterium tumefaciens nopaline synthase gene (nos) terminator.
Note:
The parental genome contains two gene cassettes: a variant of the native B. thuringiensis vegetative insecticidal protein 3Aa (vip3Aa20) and E. coli phosphomannose isomerase.
Transcription of vip3Aa20 commences at the Z. mays ubiquitin promoter and then transcribes vip3Aa20 followed by intron 9 of Z. mays phosphoenolpyruvate carboxylase, before terminating at the CaMV 35S terminator. Nigher levels of expression are expected due to the promoter and the enhancement by the intron.
The pmi coding sequence is under the control of Z. mays ubiquitin promoter and transcription terminates at the Agrobacterium tumefaciens nopaline synthase gene (nos) terminator.
Note:
- Southern blot analyses demonstrated that the T-DNA insert contains: (i) single copies of a vip3Aa20 gene and a pmi gene; (ii) two copies of the maize ubiquitin promoter; (iii) one copy of the nos terminator; and (iv) no backbone sequences from transformation plasmid pNOV1300.
- In the parental MIR162 maize, a variant of the native B. thuringiensis vegetative insecticidal protein 3Aa (vip3Aa20), named vip3Aa19, which has codon changes that result in a single M129I amino acid substitution was inserted into the transformation cassette. During the transformation process an additional DNA mutation resulted in a K284Q amino acid substitution.
DNA insert from MON89034 (MON-89Ø34-3) vector PV-ZMIR245:
Maize line MON89034 expresses two Bt-toxins encoded by Bacillus thuringiensis cry1A.105 and cry2Ab2.
Transcription of cry1A.105 begins at the Cauliflower mosaic virus (CaMV) Enhanced 35S promoter and finishes at the wheat (Triticum aestivum) wheat heat shock protein 17.3 terminator. The transcript initially includes (5' to 3'): wheat 5' untranslated leader from the chlorophyll a/b-binding protein, Oryza sativa (rice) actin 1 intron and cry1A.105. The wheat 5' untranslated leader sequence and the rice intron enhance the expression of cry1A.105.
Transcription of cry2Ab2 commences from the Figwort mosaic virus (FMV) 34S promoter and terminates at the Agrobacterium tumefaciens nopaline synthase (nos) terminator. The transcript initially includes (5' to 3'): maize heat shock protein 70 (hsp70) intron, maize transit peptide and first intron from the small subunit of ribulose-1,5-bisphosphate carboxylase/oxygenase and cry2Ab32. The hsp70 regulates and enhances gene expression, while the transit peptide targets Cry2Ab2 to the chloroplast.
Note:
- The viral promoters are expected to be constitutively active and promote high levels of transcription.
- The coding sequence of cry2Ab2 was codon-optimized for expression within plant systems.
- A second T-DNA insertion (containing CaMV 35S promoter, Escherichia coli neomycin phosphotransferase and A. tumefaciens nos terminator) was initially inserted into the genome for kanamycin selection during transformation. However, once transformants were regenerated, the selectable marker was bred out of the parental line using convention breeding techniques.
- Southern blot analyses indicated a single copy of the cry1A.105 and the cry2Ab2 cassettes. No backbone plasmid DNA or nptII sequences were detected. PCR and DNA sequence analyses provided the complete DNA sequence of the insert and confirmed the organization of the elements within the insert. Furthermore, sequence analysis indicated that MON89034 no longer has the duplicated enhancer elements compared to the original e35S promoter in PV-ZMIR245, possibly due to a recombination event that resulted in its deletion.
DNA insert from 5307 (SYN-Ø53Ø7-1) vector pSYN12274
The DNA insert contains two gene cassettes for an engineered chimeric protein eCry3.1Ab and an Escherichia coli phosphomannose isomerase (pmi).
Transcription of ecry3.1Ab is under control of a Cestrum yellow leaf curling virus promoter and an Agrobacterium tumefaciens nopaline synthase (nos) terminator. Transcription of pmi is under control of a Zea mays ubiquitin gene promoter and a nos terminator. The promoter contains the first intron of the ubiquitin gene, which will be initially included in the mRNA before splicing and for enhancing expression of pmi. Transcription is expected to be constitutive under both promoters and result in elevated levels of transgene expression.
Note:
The DNA insert contains two gene cassettes for an engineered chimeric protein eCry3.1Ab and an Escherichia coli phosphomannose isomerase (pmi).
Transcription of ecry3.1Ab is under control of a Cestrum yellow leaf curling virus promoter and an Agrobacterium tumefaciens nopaline synthase (nos) terminator. Transcription of pmi is under control of a Zea mays ubiquitin gene promoter and a nos terminator. The promoter contains the first intron of the ubiquitin gene, which will be initially included in the mRNA before splicing and for enhancing expression of pmi. Transcription is expected to be constitutive under both promoters and result in elevated levels of transgene expression.
Note:
- eCry3.1Ab is a result of a fusion of the 5′ end (Domain I, Domain II and 15 amino acids of Domain III) of a modified Cry3A gene and the 3′ end (Domain III and Variable Region 6) of a synthetic cry1Ab gene. The sequences were sourced from Bacillus thuringiesis.
- Southern blot analysis indicated that the parental line contains a single insertion of the vector and there was no integration of the vector backbone.
- Sequencing analysis indicated that the right and left T-DNA borders were truncated.
For more information, kindly refer to the parental LMO records.
EN
- Feed
- Food
- MON-89Ø34-3 - EU Reference Laboratory for GM Food and Feed (EURL-GMFF) ( JRC ) [ English ]
- SYN-Ø53Ø7-1 - EU Reference Laboratory for GM Food and Feed (EURL-GMFF) ( JRC ) [ English ]
- SYN-IR162-4 - EU Reference Laboratory for GM Food and Feed (EURL-GMFF) ( JRC ) [ English ]
- SYN-IR162-4 - CropLife International Detection Methods Database ( CropLife ) [ English ]
- MON-89Ø34-3 - CropLife International Detection Methods Database ( CropLife ) [ English ]
- SYN-Ø53Ø7-1 - CropLife International Detection Methods Database ( CropLife ) [ English ]
EN
EN
- EUginius - MIR162 x MON89034 x 5307 [ English ]
